Product Overview
PVC Coated Welded Mesh is manufactured from high-tensile steel wire, typically galvanized or low carbon steel, welded into a rigid grid structure and finished with a fluidized bed PVC coating system.
The coating is applied through a full thermal dipping process using UV-stabilized PVC compounds, forming a continuous protective layer over the wire surface and welded joints.
The product is designed for fencing and enclosure systems used in residential, agricultural, and industrial environments requiring long-term outdoor exposure.
Product Parameters
|
Height |
0.6m, 1.2m, 1.5m, 1.8m, 2.4m |
|
Opening (w × h) |
2" × 2", 2" × 4", 3" × 3" (or 50×50mm - 75×75mm) |
|
V-Curves (Strengthening Rails) |
2 (for 0.6m & 1.2m), 3 (for 1.5m), 4 (for 1.8m), 5 (for 2.4m) |
|
Gauge |
6 |
|
Wire breaking load |
80,000-100,000 PSI |
|
Weld-shear strength |
1,051 lbs |
|
Galvanized |
0.50 oz/sq.ft |
|
PVC coating thickness |
0.8 mm – 1.5 mm (approx. 31–59 mils via Full Thermal Dipping) |
|
Colors |
Green (RAL 6005), Black (RAL 9005), Yellow, Brown, White, Gray and more custom RAL codes |
Advanced Thermal Dipping & Technical Advantages
Dual-layer protection combining a steel core with a thermal-bonded PVC layer to resist rust in high-humidity and coastal environments.
Full thermal dipping process encapsulates the grid, including overlapping weld joints, to seal out moisture entry points.
Thick PVC coating ranging from 0.8 mm to 1.5 mm shields the inner wire from impacts and abrasive handling.
Automated CNC resistance welding delivers consistent joint strength to reduce weld separation during high-tension installation.
Lead-free and phthalate-free PVC materials comply with RoHS and REACH standards for efficient import customs clearance.
Uniform mesh apertures and precise line gauges allow for practical cutting, alignment, and framing on site.
Target Applications for Wholesalers
Commercial & Perimeter Fencing
Ideal for supplying local contractors for industrial zones, residential borders, and sports field enclosures.
Agricultural & Aquaculture Enclosures
Heavy-duty wire gauges specifically suited for poultry cages, livestock fencing, and marine farming grids.
Industrial Safety Barriers
Standard panel sizes ready for machine guards, warehouse partition screens, and transport infrastructure protection.
Compliance & Certificate Verification
Traceable Mill Test Certificates (MTC): Every single shipment is accompanied by an MTC documenting the exact chemical composition of the steel and zinc-layer density.
Regulatory Paperwork: Full test reports for RoHS, REACH, and tensile strength are provided instantly to streamline your local environmental and import compliance.
Packaging & Surface Protection
PVC Coated Welded Mesh panels are wrapped with protective film to reduce surface abrasion during handling and transportation.
Panels are stacked on pallets to maintain shape stability and facilitate forklift loading.
Edge protection materials are used to reduce friction damage between panels during shipment.
Container loading is optimized to ensure stable stacking and minimize movement during transit.
