The machine guarding safety fence features a modular, high-strength welded structure that ensures visual transparency while physically isolating personnel from machinery. Not only does it comply with international safety distance standards, but-thanks to its wear-resistant and anti-corrosive industrial-grade coating-it also provides automated workshops with high-performance impact protection and safety warning capabilities.
Technical Parameters
|
Item |
Specification |
|
Structural form |
Modular frame system (wire mesh + posts) |
|
Standard height |
1600 / 1800 / 2000 / 2200 mm |
|
Standard width |
500 / 800 / 1000 / 1200 mm |
|
Mesh size |
20×100 mm (anti-finger insertion design) |
|
Frame profile |
20×30 mm / 30×30 mm steel tube |
|
Surface treatment |
Hot-dip galvanizing + powder coating |
|
Compliance |
ISO 14120 / OSHA 1910.212 / CE standard |
The Machine Guarding Safety Fence can be customized based on production layout, machine type, and safety zoning requirements.
Key Features
Modular & Fast Installation
Bolt-connected modular design enables tool-free alignment and rapid installation. A single panel can typically be installed in ≤5 minutes, supporting fast production line adjustment and relocation.
Industrial Corrosion Protection
Double protection system (hot-dip galvanizing + powder coating) ensures long-term durability in industrial environments, with a designed service life of 15+ years under normal factory conditions.
Safety System Integration Ready
Pre-designed interfaces support integration with:
Safety interlock switches
Safety doors (sliding or swing types)
PLC-controlled access systems
Emergency stop system coordination
This makes the Machine Guarding Safety Fence suitable for smart factory automation environments.
Application Areas
Automotive Manufacturing
Welding robot isolation
Final assembly line protection
EV battery assembly safety zones
Machining Industry
CNC machine guarding
Stamping press safety fencing
Grinding and cutting workstation isolation
Logistics & Warehousing
AGV route separation
Automated warehouse safety fencing
Sorting system protection
Food & Packaging Industry
Filling line safety enclosure
Palletizing robot isolation systems
Quality Control System
To ensure industrial reliability, Binze applies a three-level inspection system for every batch of Machine Guarding Safety Fence:
Incoming Material Inspection
Steel mechanical property testing
Powder coating batch melt index verification
In-Process Inspection
Weld point shear strength sampling (every 2 hours)
Real-time coating thickness monitoring
Finished Product Inspection
100% dimensional inspection
Salt spray corrosion resistance sampling tests
Monthly impact destructive testing for validation
This ensures each Machine Guarding Safety Fence meets consistent industrial-grade performance standards.
Trade Information
MOQ
50–100 sets (based on specification)
Lead Time
15–25 days after order confirmation
Payment Terms
T/T, L/C at sight
Trade Terms
EXW / FOB / CIF available
