Expanded Mesh Fence is a high-strength security fencing system manufactured by stamping and stretching a single steel sheet into a continuous mesh structure. Unlike welded mesh fencing, it contains no welded joints within the mesh area, providing greater rigidity, impact resistance, and long-term durability.

Technical Specifications

Item	Specification
Material	Q235 Carbon Steel, Pre-Galvanized Steel, Stainless Steel 304/316
Panel Height	0.5 m – 4.0 m
Panel Width	1.5 m – 3.0 m
Standard Mesh Openings	25 × 25 mm, 50 × 100 mm
Surface Treatment	Hot-Dip Galvanized, Powder Coated, PVC Coated
Zinc Coating Thickness	40–120 μm
Powder Coating Thickness	60–80 μm
PVC Coating Thickness	0.5–1.0 mm
Color	Standard and Full RAL Color Range
Post Type	Square Post or Round Post

Custom specifications can be produced according to project drawings and tender requirements.

Custom Manufacturing Options

Custom Dimensions
Fence height can be customized from 0.5 m to 4.0 m, while panel width is available from 1.5 m to 3.0 m.
Beyond standard mesh patterns, non-standard mesh openings and panel configurations can be manufactured according to customer drawings.

Material Selection
Different material grades are available to meet various performance and budget requirements:

Q235 low-carbon steel
Pre-galvanized steel
Stainless steel 304
Stainless steel 316

For coastal, chemical, and marine environments, stainless steel options provide superior corrosion resistance.

Surface Finishing

Hot-Dip Galvanized

Provides a zinc coating thickness of 40–120 μm for long-term outdoor protection.

Powder Coated

Available in the full RAL color range with coating thickness of 60–80 μm.

PVC Coated

Provides an additional protective layer with thickness ranging from 0.5–1.0 mm.

Duplex Protection System

For maximum durability, we recommend combining galvanizing with powder coating or PVC coating.

Typical Applications

Expanded Mesh Fence is widely used in:

Manufacturing facilities

Warehouses and logistics centers

Airports and railway projects

Power plants and substations

Solar energy projects

Water treatment facilities

Public infrastructure projects

Government facilities

High-security compounds

Construction site protection

The fence provides an effective balance between security, visibility, ventilation, and long-term durability.

Packaging & Export Support

To reduce transportation damage and improve unloading efficiency, all fencing products are packaged using export-standard methods.

Standard Packaging

Anti-rust protective film
Waterproof woven wrapping
Wooden pallets or steel frames
Corner protection for sharp edges
Separate packaging for accessories

Customized Export Services

Shipping mark printing
Barcode labeling
QR code labeling
Mixed-container loading plans
Customized packaging requirements

Container loading arrangements are optimized according to shipment volume to maximize loading efficiency and reduce freight costs.

Quality Assurance

Every production batch undergoes inspection before shipment, including:

Raw material verification

Dimensional inspection

Mesh opening inspection

Surface treatment inspection

Coating thickness testing

Packaging inspection

Material certificates and inspection reports can be supplied upon request.

FAQ

Q: When can I receive a quotation?

A: Most quotations are provided within 12–24 hours after receiving complete specifications.

Q: What is your MOQ for Expanded Mesh Fence?

A: Standard MOQ is one 20GP container, while trial orders can be discussed.

Q: Can you manufacture according to drawings?

A: Yes, customized production based on technical drawings and project specifications is available.

Q: What payment methods do you accept?

A: T/T, L/C at sight, and other mutually agreed payment terms are supported.

Q: Which trade terms can you provide?

A: EXW, FOB, CFR, CIF, DDP, and other Incoterms are available.

Q: How do you control product quality?

A: Raw materials, production processes, coating quality, and finished products are inspected before shipment.

Q: Can the fence color be customized?

A: Yes, any standard RAL color can be produced according to project requirements.

Q: What is the typical production lead time?

A: Normally 15–30 days depending on quantity, specifications, and coating requirements.

Q: What packaging method do you use?

A: Panels are packed with anti-rust film, waterproof wrapping, and wooden pallets or steel frames.

Q: What certificates can you provide?

A: Material certificates, inspection reports, and quality management documentation are available upon request.

Q: Is maintenance difficult?

A: No, the corrosion-resistant finish requires only minimal periodic cleaning and inspection.

Q: Do you provide installation support?

A: Yes, installation drawings and technical assistance can be provided for projects.
